PMMA Acrylic Panel for Swimming Pool

What is PMMA Acrylic

PMMA stands for polymethyl methacrylate, which is commonly known as acrylic or acrylic glass. PMMA acrylic is a highly transparent material with excellent resistance to ultraviolet radiation and weathering and is widely used as a lightweight and shatter-resistant alternative to glass.

It can be colored, molded, cut, drilled and formed. These properties make it ideal for many outdoor applications like in swimming pools and water features.

Overall, PMMA acrylic is a versatile material with a wide range of applications across industries due to its optical clarity, lightweight, durability, and ease of fabrication.

Windows and Glazing: Acrylic is commonly used in windows, skylights, and other glazing applications due to its clarity, lightweight, and impact resistance.
Signage and Displays: PMMA acrylic is widely used in signage, point-of-purchase displays, and illuminated signs due to its optical clarity and ease of fabrication.
Lighting Fixtures: Acrylic is often used as a diffuser material in lighting fixtures to distribute light evenly and reduce glare.
Aquariums and Fish Tanks: Acrylic is a popular material for aquariums and fish tanks due to its clarity, strength, and ability to be formed into complex shapes.
Furniture: Acrylic is used in furniture design for items such as tables, chairs, and shelving due to its modern appearance and durability.
Medical Devices: PMMA acrylic is used in various medical devices and equipment components due to its biocompatibility and transparency.
Automotive: Acrylic is used in automotive applications such as headlight lenses, taillight covers, and instrument panels due to its optical properties and impact resistance.

Where is PMMA Acrylic used

Acrylic is formed by a traditional process called bulk polymerization where the monomer and catalyst are poured into a mold and the reaction takes place.

The mold for producing sheets is assembled from two plates of polished glass separated by a flexible "window-frame" spacer. The spacer sits along the outer perimeter of the surface of the glass plates and forms a sealed cavity between the plates. The flexible spacer allows the mold cavity to shrink during the polymerization process to compensate for the volume contraction of the material as the reaction goes from individual molecules to link polymers.

AN open corner of each mold cavity is filled with pre-measured liquid syrup of methyl methacrylate monomer and catalyst which flows throughout the mold cavity to fill it.

The mold is then sealed for the reaction to take place. In the reaction, heat is generated but is fanned off in air ovens or is totally immersed in water. A programmed temperature cycle regime will ensure proper cure time without additional vaporization of the monomer solution. This will prevent the bubbles from forming. Cure time takes an average of 5-7 days depending on the thickness. When curing is done in a dry kiln facility, it allows high temperature above 110° Celsius. The high temperature reduces residue stresses or impurities in the material that might cause warping and other dimensional instabilities.

In the dry kiln, and after curing, acrylic panels can be formed to any shapes and curves according to templates.

How is PMMA Acrylic manufactured

Grow Your Vision

Welcome visitors to your site with a short, engaging introduction.

Double click to edit and add your own text.

The forming of acrylic dome is a process called "vacuum forming". The size of the dome can be customized to vary to varying heights. The thickness of the panel to use depends on the span of the diameter.

Acrylic Dome

Why use Acrylic over glass

Acrylic is often preferred over glass for various applications due to its unique properties and advantages. Here are some reasons why acrylic is chosen over glass:

Impact Resistance: Acrylic is much more impact-resistant than glass. It is less likely to shatter or break upon impact, making it a safer choice for applications where safety is a concern, such as in children's toys, safety barriers, or protective screens.
Lightweight: Acrylic is significantly lighter than glass, making it easier to handle, transport, and install. This property makes it an ideal choice for applications where weight is a consideration, such as in signage, display cases, or aircraft windows.
Transparency: Acrylic offers excellent optical clarity, similar to glass, allowing light to pass through with minimal distortion. It is often used in applications where transparency is essential, such as in windows, skylights, or aquariums.
UV Resistance: Acrylic is inherently resistant to UV radiation from the sun. Unlike glass, which can degrade or yellow over time when exposed to sunlight, acrylic maintains its clarity and appearance, making it suitable for outdoor applications such as signage, outdoor furniture, or architectural glazing.
Ease of Fabrication: Acrylic can be easily cut, drilled, machined, thermoformed, and bonded using standard tools and techniques. It is more flexible and less prone to chipping or cracking during fabrication compared to glass, allowing for more intricate designs and custom shapes.
Thermal Insulation: Acrylic provides better thermal insulation than glass, helping to retain heat indoors and reduce energy costs. It is often used in windows, greenhouse panels, and skylights to improve energy efficiency and indoor comfort.
Chemical Resistance: Acrylic is resistant to many chemicals, including acids and alkalis, making it suitable for use in harsh environments where exposure to corrosive substances is a concern.
Durability: Acrylic is highly durable and resistant to scratching, abrasion, and weathering. It maintains its appearance and performance over time with minimal maintenance, making it suitable for long-term use in both indoor and outdoor applications.

Overall, the unique combination of properties offered by acrylic makes it a versatile material suitable for a wide range of applications across industries, from construction and architecture to automotive, electronics, and consumer goods.
